NEW GoodWe GW9600A-TX Auto Transformer (120V/240V Split Phase Backup) - $199 (milpitas)
condition:
new
make / manufacturer:
GoodWe
model name / number:
GW9600A-TX
size / dimensions:
13.6" × 10.9" × 6.9"
QR Code Link to This Post
Designed specifically for GoodWe A-ES and A-BP series hybrid/retrofit energy storage inverters to balance 120V/240V split-phase backup loads during grid-tied and off-grid/backup operation. Features robust outdoor Type 4X weatherproofing and quiet natural convection cooling.
PRICING & VOLUME OPTIONS:
• Single Unit (1 unit): $199
• 2 Units: $189 each ($378 total)
• 3 Units: $179 each ($537 total)
• 4+ Units (Bulk): $169 each
KEY SPECIFICATIONS:
• Manufacturer: GoodWe
• Model: GW9600A-TX
• Function: Auto Transformer (ATX) for 120V/240V split-phase load balancing
• Max Continuous Rated Power (L-N): 4,800 VA
• Rated Voltage: 120V / 240V Split Phase (60 Hz)
• Max Continuous Output Current Per Phase @ 120V: 40A
• Split Phase Imbalance Current @ Rated Power: 40A
• Protection: Built-in Thermal Protection
• Enclosure Rating: NEMA Type 4X (outdoor/indoor wall-mount)
• Cooling: Natural Convection (ultra-quiet, <25 dB)
• AC Conduit Size: 1 inch
• Weight: 48.5 lbs (22 kg)
• Dimensions: 13.6" × 10.9" × 6.9"
COMPATIBILITY:
• GoodWe A-ES Series Hybrid Inverters (e.g., GW7600A-ES, GW9600A-ES)
• GoodWe A-BP Series AC-Coupled Storage Inverters (e.g., GW7600A-BP)
• Essential for whole-home or critical-load 120V/240V balancing in solar + storage setups
COMPLETE SOLAR & STORAGE SYSTEM COMPONENTS AVAILABLE:
• GoodWe GW7600A-BP 7.6kW AC-Coupled Storage Inverters ($499)
• CATL 5.12kWh 48V LiFePO4 Battery Modules ($690)
• Kohler Power Reserve 20kWh Energy Storage Systems ($3,900)
* Package discounts available if bundling inverters, batteries, and transformers together!
CONDITION & PICKUP:
• Condition: 100% Brand New in original box.
• Pickup: Available for local pickup in San Jose / Milpitas / South Bay.
To browse all my available solar gear, EV conversion parts, batteries, and industrial electronics, search NorCalTechSurplus in the Craigslist search bar.
Tags: GoodWe, auto transformer, autotransformer, split phase, 120V 240V balancing, GW9600A-ES, GW7600A-ES, solar inverter, battery backup, off-grid power, Sol-Ark, Victron, Schneider, critical loads panel.
