Generac Automatic Transfer Switch for standby generator. - $425 (Portland)
condition:
like new
make / manufacturer:
Generac
model name / number:
rxg16eza3
size / dimensions:
30.1' X 13.5' X 6.91'
QR Code Link to This Post
Generac 100-Amp Outdoor Automatic Transfer Switch
Designed to operate with Generac air-cooled generators (7-16kW Only)
16-Circuit Integrated Load Center For Essential Circuit Backup
For large main service and only partial generator backup
Also when main electrical breaker panel is located outdoors
16-Circuit Breaker Panel (Breakers Not Included)
Use with Siemens, Eaton, or Square D 1-Inch breakers
Expandable to 24-Circuits
Bottom (4) breaker spaces will accommodate tandem breakers
UL/CUL Listed
Suitable for use in optional standby systems (NEC702)
Aluminum NEMA 3R Indoor/Outdoor Enclosure
Electrostatically applied and baked powder paint to resist corrosion
Heavy Duty Generac Contactor - Rated @ 250 VAC - 1P
UL recognized device, designed for years of service
*Note - Generator controller handles all timing, sensing and exercise
Tech Spec: Only For Use with Generac Air-Cooled Generators
Load Transition Type: Open Transition
Withstand Rating: 10,000 Amps --- Lug Range: 1/0 - #14
