Redgum integrated amplifier rgi 35 - $300 (Happy Valley)
condition:
good
make / manufacturer:
Redgum rgi 35
model name / number:
RGI 35
size / dimensions:
16 1/2 W x 14 L x 3 1/2 H
QR Code Link to This Post
Technical Specifications
Power Output: 35 W + 35 W RMS continuous into 8 ohms (90 W + 90 W RMS transient)
Harmonic Distortion: < 0.009% (below clipping)
Intermodulation Distortion: < 0.005% (below clipping)
Signal-to-Noise Ratio: > 100 dB
Frequency Response: 0.8 Hz to 80 kHz (-3 dB points)
Input Impedance: 10K ohms (matches 600 ohms to 50K ohms)
Damping Factor: > 150
Slew Rate: > 65 V/microsecond
Peak Current: > 120 amps
Connectivity & Build
Audio Inputs: 5 inputs (CD1, AV1, DVD, CD2, AV2) with color-coded connections
Design: Dual MOSFET per channel, dual-mono volume architecture
Chassis Finish: High-gloss solid Red Gum wood fascia with a thick black gloss steel housing
Dimensions: 420 mm (W) x 360 mm (D) x 95 mm (H) / 16.5 in (W) x 14.2 in (D) x 3.75 in (H)
Weight: Shipping weight approx. 9 kg (20 lb)
