GEKA 110 SD Dual operator Ironworker. - $7,000
QR Code Link to This Post
Tonnage: 110 Ton
Shearing Power: 180 Ton
Punching: 1-1/16” x 1/2”
Flat Bar: 24” x 5/8” or 16” x 3/4”
Length of Blade: 24”
Notching: 1/2”
L at 90 Degrees without Deformation: 6” x 6” x 1/2”
L at 45 Degrees: 2-3/4” x 2-3/4” x 1/4”
Throat Depth: 24”
Model: 110/SD
Voltage: 440v
Phase: 3
Features: Dual cylinders allowing two operators to use at the same time
Width: 48”
Length: 98”
Height: 80”
This machine has been lightly used and does not show signs of abuse. The shear used to cut sold round/square stock appear to rarely have been used based on the provided close up photos, the factory machine marks are clearly visible. All blades are acceptable with light wear and do not appear to need replacement. The machine is mounted onto a custom frame with heavy duty dual wheels. The frame has a very low center of gravity allowing for safe transport. The unit can connect to a towing hitch on either end for movement in tight spots or offloaded from a tilt deck when a crane or forklift are not available. This unit was winched onto a tilt deck trailer after draining the hydraulic fluid with no issues. All new hydraulic fluid just installed. The custom frame ends slide off allowing for quick and safe lowering of the machine once transport/placement has been completed
Delivery available at very reasonable rates, please email me if you have any questions.
Keywords: Ironworker, scotchman, jet, uni-hydro, metalpro, buffalo, piranha, baileigh, edwards, kalamazoo, metal muncher, raymax, olivette, kingsland, kaka, sunrise, daramco, Morgan, Rushworth, HSW, spartan, punch, shear, cut, notch, bend, bending, form, shearing, punching, coping, bending,
