Biddle Megger Earth (Ground) Tester model 25-40j - $45 (Mountain home)
QR Code Link to This Post
The Biddle Megger Earth Tester (frequently associated with models like the 250220 or 25-J series) is a legacy instrument designed for measuring the resistance of grounding systems, such as ground rods and earth electrode networks. These vintage units are renowned for their rugged construction and reliability, often using a hand-cranked generator (magneto) to produce the necessary test voltage, eliminating the need for batteries.
Key Features of Biddle Earth Testers
Measurement Method: These units generally use a 3-terminal method to measure resistance, often utilizing a "null balance" mechanism to achieve accurate, direct readings in Ohms.
Power Source: The "Megger" name comes from the combination of "Megohm" and "generator," referring to the hand-cranked magneto which delivers consistent test voltage.
Application: Used to test ground electrode resistance for low-voltage installations, ensuring they meet safety compliance standards.
Display: Many vintage 25-J models feature an analog dial scale and a pointer for manual null balancing.
JM Test Systems
JM Test Systems
+4
Typical Operation (Null Balance Models)
Connections: Connect the E (Earth) terminal to the ground electrode under test, and the C and P terminals to temporary stakes driven into the earth.
Crank: Turn the hand crank at a steady speed (usually around 100-150 rpm) to generate the test voltage.
Balance: While cranking, turn the calibrated dial until the galvanometer pointer rests at zero (the null point).
Read: Read the ground resistance value directly from the dial.
JM Test Systems
JM Test Systems
+4
Important Safety and Maintenance
Testing Setup: The accuracy of the result depends heavily on the proper placement of the test stakes, usually arranged in a straight line.
Maintenance: Being vintage mechanical instruments, they often require care for the mechanical magneto and calibration of the internal resistors.
Discharge: Although earth testers use lower voltages than insulation testers, it is standard practice to ensure the system is de-energized before testing.
