SNEdge RGB Bypass Mod Kit - Video Signal Upgrade for 2-Chip SNES & Super Famicom - $44 (Maple Shade)
QR Code Link to This Post
Transform the video output quality of your original 2-Chip Super Nintendo or Super Famicom with the SNEdge RGB Bypass Mod Kit. Designed to resolve the infamous horizontal smearing and muddy pixel clarity common to early 2-Chip motherboard revisions, this board extracts and amplifies clean RGB video lines to deliver crisp, razor-sharp 1-Chip level visuals on CRT monitors and digital upscalers.
TECHNICAL SPECIFICATIONS & DESIGN HIGHLIGHTS:
ELIMINATES 2-CHIP COLOR SMEARING & GHOSTING: Bypasses the aging factory video encoder and filters to eliminate horizontal shadow trails, bleeding edges, and dark banding across classic 16-bit sprites.
1-CHIP LEVEL CLARITY ON 2-CHIP HARDWARE: Restores clean edge definition and high color saturation, giving your early SNES/SFC console the visual sharpness of rare and expensive 1-Chip systems.
LOW-NOISE VIDEO AMPLIFIER ARCHITECTURE: Engineered with precision video filtering and $75\Omega$ impedance-matched output stages to deliver low-noise video signals directly to the Nintendo Multi-Out connector.
DIRECT MULTI-OUT QUICK SOLDER FIT: Features a dedicated solder-over-pin Multi-Out daughterboard for clean, solid anchor points behind the AV port.
RETRO SCALER & CRT OPTIMIZED: Designed to pair with shielded RGB SCART cables and HD Retrovision component cables for scanline accuracy on PVM/BVM CRT monitors, OSSC, and RetroTINK line doublers.
MOTHERBOARD COMPATIBILITY GUIDE:
Compatible Systems: Fits original 2-Chip Super Nintendo and Super Famicom consoles across NTSC and PAL revisions (SHVC-CPU-01, SNS-CPU-GPM-01/02, SNS-CPU-RGB-01/02, SNS-CPU-APU-01).
Skill Level: Requires basic soldering skills to attach the Multi-Out daughterboard and route the color signal
