3" WACKER NEUSON TRASH PUMP PT3A - $700 (HUDSON)
11031 SR 52
QR Code Link to This Post
MAKE: WACKER NEUSON
MODEL#: PT3A
The Wacker Neuson PT3A is a 3-inch self-priming centrifugal trash pump powered by a Honda gasoline engine.
Engine Specifications
• Engine Model: Honda GX240UT2X-QA2 (gasoline, air-cooled, single-cylinder)
• Displacement: 270 cm³
• Max Rated Power: 7.9 PS / 5.9 kW (approx. 7.9–8 hp)
• Fuel Tank Capacity: 5.3 L (1.4 gal)
Pump Performance
• Max Flow Rate: ~1,315 l/min (approx. 347 US gal/min or ~22,980 GPH)
• Suction / Discharge Diameter: 3 in (76 mm)
• Max Suction Head / Lift: 7.5 m (24.6–25 ft)
• Max Delivery Height / Head: 29.5 m – 32 m (approx. 96–99 ft)
• Max Pressure: 2.9 bar (approx. 42.1 – 42.5 psi)
• Max Solid Size Capacity: 38 mm (1.5 in)
• Impeller Material: Surface-hardened ductile iron
Dimensions & Weight
• Operating Weight: 62 kg (approx. 136–149 lbs depending on exact sub-configuration)
• Dimensions (L x W x H): ~26.5 x 20 x 22.5 in
