Dell Professional Projector S518WL - $375 (HONOLULU)
QR Code Link to This Post
The Dell S518WL Projector is a WXGA Conference Room Projector. This laser projector is capable of displaying 3,200 Lumens at its brightest setting with a native resolution of 1280x800 , and is 3D capable. The internal DLP technology touts higher contrast, less visible pixels and more portability. This projector was first available for purchase in September 2017
Brightness
3,200 Lumens (ANSI)1
Resolution
1280x800
Aspect Ratio
16:10 (WXGA)
Contrast
1,000,000:1 (full on/off)
Display Type
DLP x 1
Color Processing
10-bit
Input Lag
1080p/60: 33ms
Video Modes
720p, 1080i, 1080p/60, 1080p/24, 1080p/25, 1080p/30, 2160p/24, 535p, 540p, 575p, 576p, 1125i, 768p, 3840p/24, 4096p/24, 480p, 480i
Data Modes
MAX 1920x1080
3D Modes
PC 3D Ready
Lamp Type
Laser Phosphor
Lamp Life
20,000 hours
Included Lens
Fixed focal length , manual focus
Optional Lenses
No
Lens Shift
No
Throw Distance
2.6' - 3.7' Calculate Throw Distance
Image Size
69.67" - 99.87"
Throw Ratio
0.52:1 (D:W)
Projector Placement
For a
100
" diagonal screen, place the projector lens 3'-8" from the screen.
Digital Keystone
Vertical only
Projector Size
4.50" x 15.20" x 11.90" (HxWxD)
Weight
12.2 lbs
Internal Speakers
10.0 Watts × 2
Power
350 Watts 100V - 240V
Connection Panel
Audio In: Mini Jack
Audio Out: Mini Jack
HDMI 1.4a
MemoryCard
Network: RJ-45
RS232: DB-9pin
USB x 2
VGA Out: Dsub-15pin
Wireless Networking
Features
PC 3D Ready
Storage Device
Special Warranty
Option Slots
Short-Throw
Operate 24/7
Additional Features
A short-throw laser projector essential for education and small businesses. Featuring multiple connectivity options for seamless sharing.
Light Valve 0.65 WXGA S450 DMD, DarkChip3™
Brightness 3200 ANSI Lumens (Max.)
Contrast Ratio 1800:1 Typical (Full On/Full Off)
20000:1 High Contrast Ratio
Uniformity 80% Typical (Japan Standard - JBMA)
Number of Pixels 1280 x 800 (WXGA)
Aspect Ratio 16:9
Displayable Color 1.07 billion colors
Color Wheel Speed 2 X for Normal
Projection Lens F-Stop: F/2.7
Focal length, f=7.51 mm
No Manual Zoom Lens, Fixed
Throw ratio =0.52
Offset ratio: 115+/-5%
Projection Screen Size 70 ~ 100 inches (diagonal)
Projection Distance 2.55 ~ 3.67 ft (0.78 ~ 1.12 m)
Keysotne +/- 15 degree
Video Compatibility Component Video input via HDMI: 2160p
(24/25/60 Hz), 1080i (24/25/60 Hz), 720p (50/60
Hz), 576i/p, 480i/p
Power Supply Universal AC 100-240 V 50-60 Hz with PFC
input
Power Consumption Normal mode: 255 W ± 10% @ 110 Vac
Eco mode: 135 W ± 10% @ 110 Vac
Standby mode: < 0.5 W
Network standby: < 2 W
NOTE: By default, the projector is set to
enter power saving mode after 20 minutes
of no activity.
Audio 2 speakers x 10 watt RMS
Specifications 61
Noise Level Normal mode: 36 dB(A)
Eco mode: 32 dB(A)
Projector Weight < 12 lb (5.5 Kg)
Dimensions (W x D x H) 1.26 x 0.99 x 0.37 inches (386.5 x 303.2 x 115
mm)
Environmental Operating temperature: 5 °C - 40 °C (41 °F104 °F)
Humidity: 80% maximum
Storage temperature: 0 °C to 60 °C (32 °F to
140 °F)
Humidity: 90% maximum
Shipping temperature: -20 °C to 60 °C
(-4 °F to 140 °F)
Humidity: 90% maximum
I/O Connectors Power: One AC power socket (3-pin - C14 inlet)
VGA input: One 15-pin D-sub connector (Blue),
VGA In, for analog RGB/Component input
signals.
VGA output: One 15-pin D-sub connector (Black)
for VGA-A loop through.
Composite Video input: One Yellow RCA jack for
CVBS signal.
HDMI 1.4 input: Two HDMI 1.4 connectors for
HDMI 1.4 specification HDCP 2.2 compliant.
Analog Audio input: One 3.5 mm stereo mini
phone jack (Blue) and One pair of RCA (Red/
White)
Variable audio output: One 3.5 mm stereo mini
phone jack (Green).
0.37"(115 mm)
1.26"(386.5 mm)
0.99"(303.2 mm)
62 Specifications
USB (mini type B) port: One mini type B
connector for firmware upgrade.
USB Power (5V/1.8A): One USB Power
(5V/1.8A) for power only
RS232 port: One 9-pin D-sub for RS232
communication.
RJ-45 port: One RJ-45 connector for build-in for
network control and LAN display.
Light Source Up to 20,000 hours in Normal mode
